The HS-110 allows connecting classic synthesizers such as Moog or the Behringer System-55 modules with other Eurorack modules. It serves as a space-saving alternative to the System 55-961 Interface.
Features
- Two S-Trigger → V-Trigger converters
- Two V-Trigger → S-Trigger converters
- Kit with pre-soldered SMD components (suitable for soldering beginners)
- Pre-assembled version available at extra cost
- Includes PCB, aluminium front panel, jacks, 10-to-16 pin power cable, M3 mounting screws
Specifications
| Width | 4 HP / 4 TP / 14,8 mm |
|---|---|
| Module depth | 30 mm |
| V-Trigger output voltage | 12 V |
| Current draw +12V | 5 mA |
| Current draw −12V / 5V | 0 mA |
| UVP / RRP | €39,99 incl. VAT |
| EAN | 4270002676503 |
